VB API Fundamentals - Feature LIST

Feature LIST VBA Excel Program



Part 파일의 모든 Feature들의 타입 이름을 List로 만들어 주는 프로그램. frature 번호, 타입, 상태를 알수 있다.



A program that makes the type names of all the features in the part file into a list.  The fracture number, type, and condition are known.







Source code

Sub feature_Nanme()

    Dim asynconn As New pfcls.CCpfcAsyncConnection
    Dim conn As pfcls.IpfcAsyncConnection
    Dim session As pfcls.IpfcBaseSession
    Dim oModel As pfcls.IpfcModel

    Set conn = asynconn.Connect("", "", ".", 5)
    Set session = conn.session
    Set oModel = session.CurrentModel
    Cells(2, 2) = oModel.Filename

    Dim oModelowner As IpfcModelItemOwner
    Set oModelowner = session.CurrentModel()


    Dim modelitems As IpfcModelItems
    Set modelitems = oModelowner.ListItems(EpfcModelItemType.EpfcITEM_FEATURE)
    Dim oFeature As IpfcFeature
    Dim i As Integer

    For i = 0 To modelitems.Count - 1
        Set oFeature = modelitems(i)
        Cells(i + 4, 2) = oFeature.FeatTypeName
        Cells(i + 4, 3) = oFeature.FeatType
        Cells(i + 4, 1) = i + 1
    Next


    'Disconnect with Creo
    conn.Disconnect (2)

End Sub



part feature list v1.xlsm

0.02MB
