IpfcSurface

□ IpfcSurface

IpfcSurface is an interface in Creo Parametric that defines a surface. It provides a set of methods and properties to interact with and analyze surfaces within the software.

▷Key Properties:

IsVisible: A boolean indicating whether the surface is visible or not.
OwnerQuilt: The quilt (a collection of surfaces and curves) that the surface belongs to.

Code : IsVisible

 Dim ModelItemOwner As IpfcModelItemOwner
 Dim ModelItems As IpfcModelItems
 Dim Surface As IpfcSurface
 Dim i As Long

 Set ModelItemOwner = Model
 Set ModelItems = ModelItemOwner.ListItems(EpfcModelItemType.EpfcITEM_SURFACE)

  For i = 0 To ModelItems.Count - 1
  		Set Surface = ModelItems(i)
        magbox Surface.IsVisible

  Next i



Code : Returns the feature which contains the geometry ( feature Number )

Dim ModelItemOwner As IpfcModelItemOwner
Dim ModelItems As IpfcModelItems
Dim Surface As IpfcSurface
Dim Quilt As IpfcQuilt
Dim Feature As IpfcFeature
Dim i As Long

Set ModelItemOwner = Model
Set ModelItems = ModelItemOwner.ListItems(EpfcModelItemType.EpfcITEM_SURFACE)

  For i = 0 To ModelItems.Count - 1
        Set Surface = ModelItems(i)
        set Quilt = Surface.OwnerQuilt
        set Feature = Quilt.GetFeature
        Msgbox Feature.Number
  Next i

▷ Key Methods:

1. Evaluation Methods:

• Eval3DData:
  Evaluates the surface at a specific UV point, returning XYZ coordinates, derivatives, and the normal vector.
• EvalArea: Calculates the surface area.
• EvalClosestPoint: Finds the closest point on the surface to a given point in 3D space.
• EvalDiameter: Calculates the diameter of the surface at a specific UV point.
• EvalMaximum/Minimum: Finds the maximum or minimum point on the surface in a given direction.
• EvalParameters: Finds the UV coordinates corresponding to a given 3D point on the surface.
• EvalPrincipalCurv: Calculates the principal curvatures and directions at a specific UV point.

2. Geometric Information Methods:

• GetFeature: Returns the feature that the surface belongs to.
• GetNURBSRepresentation:Converts the surface to a NURBS representation.
• GetOrientation: Returns the orientation of the surface.
• GetSurfaceDescriptor: Returns a data object describing the surface's geometry.
• GetSurfaceType: Returns the type of the surface (e.g., planar, cylindrical, spherical).
• GetUVExtents: Returns the minimum and maximum UV coordinates of the surface.
• GetXYZExtents: Returns the minimum and maximum XYZ coordinates of the surface.

3. Topological Methods:

• ListContours: Lists all contours on the surface.
• ListSameSurfaces:Finds other surfaces that are identical to the given surface.
• VerifyUV: Checks if a given UV point lies within the surface boundaries.

By using these methods and properties, you can perform various operations on surfaces in Creo Parametric, such as:

Analysis: Calculating surface area, curvature, and other geometric properties.
Visualization: Controlling the visibility and appearance of surfaces.
Modification: Creating new surfaces or modifying existing ones.
Intersections: Finding intersections between surfaces and other geometric entities.

The IpfcSurface interface provides a powerful toolset for working with surfaces in Creo Parametric, enabling you to automate tasks, optimize designs, and perform complex geometric analysis.



 SurfaceTypes

SurfaceType	EpfcSurfaceType	EpfcSurfaceType Number
planar surface	EpfcSURFACE_PLANE	0
cylindircal surface	EpfcSURFACE_CYLINDER	1
conic surface	EpfcSURFACE_CONE	2
toroidal surface	EpfcSURFACE_TORUS	3
surface created by linearly interpolating between two sets of curves.	EpfcSURFACE_RULED	4
surface created by revolving a curve about an axis	EpfcSURFACE_REVOLVED	5
surface created by linearly projecting a curve	EpfcSURFACE_TABULATED_CYLINDER	6
fillet surface	EpfcSURFACE_FILLET	7
Coons path surface	EpfcSURFACE_COONS_PATCH	8
spline surface	EpfcSURFACE_SPLINE	9
Non-Uniform Rational B-Spline surface	EpfcSURFACE_NURBS	10
spline surface created using cylindrical coordinates	EpfcSURFACE_CYLINDRICAL_SPLINE	11
Reserved for internal use	EpfcSURFACE_SPHERICAL_SPLINE	12
foreign surface	EpfcSURFACE_FOREIGN	13
spline surface with 2 derivatives	EpfcSURFACE_SPL2DER	14
Use this enumerated value to represent "null" passed to optional properties or method arguments.	EpfcSurfaceType_nil	15



Code : This method returns the type of surface represented by a SurfaceDescriptor.

Dim ModelItemOwner As IpfcModelItemOwner
Dim ModelItems As IpfcModelItems
Dim Surface As IpfcSurface
Dim SurfaceDescriptor As IpfcSurfaceDescriptor
Dim i As Long

Set ModelItemOwner = Model
Set ModelItems = ModelItemOwner.ListItems(EpfcModelItemType.EpfcITEM_SURFACE)


    For i = 0 To ModelItems.Count - 1

        Set Surface = ModelItems(i)
        Set SurfaceDescriptor = Surface.GetSurfaceDescriptor
        Msgbox SurfaceDescriptor.GetSurfaceType

    Next i
