VB API Fundamentals -- VBA 예제 (4) File Open

작업공간에서 코드에서 정의한 파일 이름 불러오기

Sub Newmodel()
    Dim asynconn As New pfcls.CCpfcAsyncConnection
    'Make an asynchronous connection with Creo
    Dim conn As pfcls.IpfcAsyncConnection: Set conn = asynconn.Connect("", "", ".", 5)
On Error GoTo RunError
    'Get the current session
    Dim oBaseSession As pfcls.IpfcBaseSession: Set oBaseSession = conn.session
    Dim oModel As pfcls.IpfcModel

    'Show the current Working Directory
    Cells(1, 1) = vbCrLf & oBaseSession.GetCurrentDirectory
    'Create a modeldescriptor to the Creo Model
    Dim oModelDescriptorCreate As New CCpfcModelDescriptor
    Dim oModelDescriptor As IpfcModelDescriptor
    Set oModelDescriptor = oModelDescriptorCreate.CreateFromFileName("korea01.prt")

    'Retrieve the model into the Model handle
    Set oModel = oBaseSession.RetrieveModel(oModelDescriptor)

    'Create a new window which displays the Creo Model
    Dim oWindow As pfcls.IpfcWindow: Set oWindow = oBaseSession.OpenFile(oModelDescriptor)
    oWindow.Activate

    'Massege Info Window
    Dim oSession As IpfcSession: Set oSession = oBaseSession
    Call oSession.UIShowMessageDialog(oModel.Filename, Nothing)

    'Disconnect with Creo
    conn.Disconnect (2)

    'Cleanup
    Set asynconn = Nothing
    Set conn = Nothing
    Set oBaseSession = Nothing
    Set oSession = Nothing
    Set oModel = Nothing


RunError:

    If Err.Number <> 0 Then
        MsgBox "Process Failed : Unknown error occurred." + Chr(13) + _
                "Error No: " + CStr(Err.Number) + Chr(13) + _
                "Error: " + Err.Description, vbCritical, "Error"

        If Not conn Is Nothing Then
            If conn.IsRunning Then
                conn.Disconnect (2)
            End If
        End If
    End If

End Sub

 Set oModelDescriptor = oModelDescriptorCreate.CreateFromFileName("korea01.prt")
""korea01.prt"는 사용자 PC에 저장된 파일 이름 입니다.

Call oSession.UIShowMessageDialog(oModel.Filename, Nothing)
화면에 불러온 파일 이름이 표시 됩니다.
